Full welded round pneumatic trouser diverter with interior collar for bulk transport to silos, containers and such. The change in direction of the material is operated by a pneumatic rotating actuator connected to a bistable 5/2 solenoid valve, 24V DC with limit switches. The inner plate is mounted on two ball bearings for smooth running.
These diverters are designed to be used for falling material and light pneumatic transport (for example wood chips, polystyrene, etc.) in vertical ducting and exist with or without silicone seal
| Diameter | Diameter 2 | Diameter 3 | Length | Thickness | Item ID | Edge |
|---|---|---|---|---|---|---|
| Ød, mm | Ød, mm | Ød, mm | L, mm | s, mm | ||
| 100 | 100 | 100 | 173 | 2 | BAHF000002 | fb |
| 120 | 120 | 120 | 209 | 2 | BAHF000003 | fb |
| 150 | 150 | 150 | 250 | 2 | BAHF000004 | fb |
| 150 | 150 | 150 | 250 | 3 | BAHF000010 | fb |
| 175 | 175 | 175 | 305 | 2 | BAHF000005 | fb |
| 175 | 175 | 175 | 305 | 3 | BAHF000011 | fb |
| 200 | 200 | 200 | 336 | 2 | BAHF000006 | fb |
| 200 | 200 | 200 | 336 | 3 | BAHF000012 | fb |
| 250 | 250 | 250 | 373 | 2 | BAHF000007 | fb |
| 250 | 250 | 250 | 373 | 3 | BAHF000013 | fb |
| 300 | 300 | 300 | 437 | 2 | BAHF000008 | fb |
| 300 | 300 | 300 | 437 | 3 | BAHF000014 | fb |
| 350 | 350 | 350 | 517 | 2 | BAHF000009 | fb |
| 350 | 350 | 350 | 517 | 3 | BAHF000015 | fb |
| Diameter | Diameter 2 | Diameter 3 | Length | Thickness | Item ID | Edge |
|---|---|---|---|---|---|---|
| Ød, mm | Ød, mm | Ød, mm | L, mm | s, mm | ||
| 100 | 100 | 100 | 173 | 2.00 | BBHF000002 | fb |
| 120 | 120 | 120 | 209 | 2.00 | BBHF000003 | fb |
| 150 | 150 | 150 | 250 | 2.00 | BBHF000004 | fb |
| 175 | 175 | 175 | 305 | 2.00 | BBHF000005 | fb |
| 200 | 200 | 200 | 336 | 2.00 | BBHF000006 | fb |
| 250 | 250 | 250 | 373 | 2.00 | BBHF000007 | fb |
| 300 | 300 | 300 | 437 | 2.00 | BBHF000008 | fb |
| 350 | 350 | 350 | 517 | 2.00 | BBHF000009 | fb |
