Transition pieces Flexible duct connector

Description Cabin Unit specially designed for use in high pres- sure systems where high flexibility has to be combined with minimum installation space. An internal scale makes it pos- sible to preadjust the flow in order to minimize commission- ing costs and document settings. The matching diffuser HPBDC allows the user to adjust the flow within a preadjusted range. •Adjustable damper with scale for required flowlevel- setting. •Low noise level even at pressure above 1000 Pa. •Flow range from 50 to 350 m3/h. •Easy mounting with prefitted brackets. •Excellent air distribution. •Diffuser and inlet take off fitted with Lindab Safe rub- ber gasket for perfect tightness and low noise genera- tion. •User adjustable flow within the min./max. flow range. •Adjustable mounting of diffuser for perfect fitting in ceiling. •Low weight. Options •Electrical heating element. 230V AC with selectable effects of 250, 500 or 1000 Watt. •Integrated thermostat with selectable operating tem- perature between 30-110° C. •Manuel safety switch cuts off electricity if the tempera- ture exceeds 113° C •Non-combustible mineral wool insulation •External room thermostat •Motorized flow adjustment within min and max. flow- level Materials and finish Material: Galvanised steel. Insulation: Non-flammable melamine foam plastic.
